canam_canned.cpp File Reference

Functions
static void	cannedsparkDwellValues ()
static void	canneddwellVoltageCorrValues ()
static void	cannedidleAdvanceBins ()
static void	cannedcltIdleRpm ()
static void	cannedidleAdvance ()
static void	cannedignitionRpmBins ()
static void	cannedignitionLoadBins ()
static void	cannedveRpmBins ()
static void	cannedveLoadBins ()
static void	cannedboostRpmBins ()
static void	cannedpedalToTpsRpmBins ()
static void	cannedcltIdleCorr ()
static void	cannedcltCrankingCorr ()

Function Documentation

cannedboostRpmBins()

static void cannedboostRpmBins ( )

static

Definition at line 56 of file canam_canned.cpp.

                                 {
#if (BOOST_LOAD_COUNT == 8) && (BOOST_RPM_COUNT == 8)
    static const float hardCodedboostRpmBins[8] = {0.0, 1100.0, 2300.0, 3400.0, 4600.0, 5700.0, 6900.0, 8000.0};
    copyArray(config->boostRpmBins, hardCodedboostRpmBins);
#endif
}

Referenced by setMaverickX3().

Here is the caller graph for this function:

cannedcltCrankingCorr()

static void cannedcltCrankingCorr ( )

static

Definition at line 73 of file canam_canned.cpp.

                                    {
    static const float hardCodedcltCrankingCorr[8] = {1.0, 1.0, 1.0, 0.8, 0.8, 0.8, 0.8, 0.8};
    copyArray(config->cltCrankingCorr, hardCodedcltCrankingCorr);
}

Referenced by setMaverickX3().

Here is the caller graph for this function:

cannedcltIdleCorr()

static void cannedcltIdleCorr ( )

static

Definition at line 68 of file canam_canned.cpp.

                                {
    static const float hardCodedcltIdleCorr[16] = {1.1, 1.1, 0.9333, 0.9333, 0.9333, 0.8333, 0.6333, 0.6333, 0.5, 0.5, 0.4667, 0.3, 0.3, 0.3, 0.3, 0.3};
    copyArray(config->cltIdleCorr, hardCodedcltIdleCorr);
}

Referenced by commonGenesisCoupe(), and setMaverickX3().

Here is the caller graph for this function:

cannedcltIdleRpm()

static void cannedcltIdleRpm ( )

static

Definition at line 18 of file canam_canned.cpp.

                               {
    static const float hardCodedcltIdleRpm[16] = {1860.0, 1860.0, 1800.0, 1700.0, 1660.0, 1600.0, 1560.0, 1500.0, 1500.0, 1460.0, 1460.0, 1440.0, 1400.0, 1400.0, 1500.0, 1600.0};
    copyArray(config->cltIdleRpm, hardCodedcltIdleRpm);
}

Referenced by setMaverickX3().

Here is the caller graph for this function:

canneddwellVoltageCorrValues()

static void canneddwellVoltageCorrValues ( )

static

Definition at line 8 of file canam_canned.cpp.

                                           {
    static const float hardCodeddwellVoltageCorrValues[8] = {1.26, 1.2, 1.16, 1.1, 1.06, 1.0, 0.9, 0.8};
    copyArray(config->dwellVoltageCorrValues, hardCodeddwellVoltageCorrValues);
}

Referenced by setMaverickX3().

Here is the caller graph for this function:

cannedidleAdvance()

static void cannedidleAdvance ( )

static

Definition at line 23 of file canam_canned.cpp.

                                {
    static const float hardCodedidleAdvance[8] = {10.0, 10.571428, 11.142858, 11.714286, 12.285714, 12.857142, 13.428572, 14.0};
    copyArray(config->idleAdvance, hardCodedidleAdvance);
}

Referenced by setMaverickX3().

Here is the caller graph for this function:

cannedidleAdvanceBins()

static void cannedidleAdvanceBins ( )

static

Definition at line 13 of file canam_canned.cpp.

                                    {
    static const float hardCodedidleAdvanceBins[8] = {600.0, 800.0, 1000.0, 1200.0, 1400.0, 1600.0, 1800.0, 2000.0};
    copyArray(config->idleAdvanceBins, hardCodedidleAdvanceBins);
}

Referenced by setMaverickX3().

Here is the caller graph for this function:

cannedignitionLoadBins()

static void cannedignitionLoadBins ( )

static

Definition at line 35 of file canam_canned.cpp.

                                     {
#if (IGN_RPM_COUNT == DEFAULT_IGN_RPM_COUNT) && (IGN_LOAD_COUNT == DEFAULT_IGN_LOAD_COUNT)
    static const float hardCodedignitionLoadBins[16] = {15.0, 27.0, 33.0, 45.0, 57.0, 69.0, 81.0, 93.0, 105.0, 129.0, 157.0, 186.0, 214.0, 243.0, 271.0, 300.0};
    copyArray(config->ignitionLoadBins, hardCodedignitionLoadBins);
#endif
}

Referenced by setMaverickX3().

Here is the caller graph for this function:

cannedignitionRpmBins()

static void cannedignitionRpmBins ( )

static

Definition at line 28 of file canam_canned.cpp.

                                    {
#if (IGN_RPM_COUNT == DEFAULT_IGN_RPM_COUNT) && (IGN_LOAD_COUNT == DEFAULT_IGN_LOAD_COUNT)
    static const float hardCodedignitionRpmBins[16] = {800.0, 1000.0, 1300.0, 1600.0, 2000.0, 2500.0, 3000.0, 3600.0, 4000.0, 4400.0, 4900.0, 5300.0, 5800.0, 6200.0, 7100.0, 8000.0};
    copyArray(config->ignitionRpmBins, hardCodedignitionRpmBins);
#endif
}

Referenced by setMaverickX3().

Here is the caller graph for this function:

cannedpedalToTpsRpmBins()

static void cannedpedalToTpsRpmBins ( )

static

Definition at line 63 of file canam_canned.cpp.

                                      {
    static const float hardCodedpedalToTpsRpmBins[8] = {0.0, 1100.0, 2300.0, 3400.0, 4600.0, 5700.0, 6900.0, 8000.0};
    copyArray(config->pedalToTpsRpmBins, hardCodedpedalToTpsRpmBins);
}

Referenced by setMaverickX3().

Here is the caller graph for this function:

cannedsparkDwellValues()

static void cannedsparkDwellValues ( )

static

Definition at line 3 of file canam_canned.cpp.

                                     {
    static const float hardCodedsparkDwellValues[8] = {4.0, 3.3, 3.2, 3.1, 3.05, 2.97, 2.88, 2.8};
    copyArray(config->sparkDwellValues, hardCodedsparkDwellValues);
}

Referenced by setMaverickX3().

Here is the caller graph for this function:

cannedveLoadBins()

static void cannedveLoadBins ( )

static

Definition at line 49 of file canam_canned.cpp.

                               {
#if (IGN_LOAD_COUNT == DEFAULT_IGN_LOAD_COUNT) && (IGN_RPM_COUNT == DEFAULT_IGN_RPM_COUNT)
    static const float hardCodedveLoadBins[16] = {15.0, 27.0, 33.0, 45.0, 57.0, 69.0, 81.0, 93.0, 105.0, 129.0, 157.0, 186.0, 214.0, 243.0, 271.0, 300.0};
    copyArray(config->veLoadBins, hardCodedveLoadBins);
#endif
}

Referenced by setMaverickX3().

Here is the caller graph for this function:

cannedveRpmBins()

static void cannedveRpmBins ( )

static

Definition at line 42 of file canam_canned.cpp.

                              {
#if (IGN_LOAD_COUNT == DEFAULT_IGN_LOAD_COUNT) && (IGN_RPM_COUNT == DEFAULT_IGN_RPM_COUNT)
    static const float hardCodedveRpmBins[16] = {800.0, 1000.0, 1300.0, 1600.0, 2000.0, 2500.0, 3000.0, 3600.0, 4000.0, 4400.0, 4900.0, 5300.0, 5800.0, 6200.0, 7100.0, 8000.0};
    copyArray(config->veRpmBins, hardCodedveRpmBins);
#endif
}

Referenced by setMaverickX3().

Here is the caller graph for this function:

Go to the source code of this file.
