mmc_card_util.h File Reference

Functions
void	incLogFileName (FIL *fd)
void	printFatFsError (const char *str, FRESULT f_error)
void	writeErrorReportFile ()

Function Documentation

incLogFileName()

void incLogFileName

(

FIL *

fd

)

Definition at line 18 of file mmc_card_util.cpp.

                             {
    // clear the memory
    memset(fd, 0, sizeof(FIL));
    // This file has the index for next log file name
    FRESULT ret = f_open(fd, LOG_INDEX_FILENAME, FA_READ);

    char data[_MAX_FILLER];
    memset(data, 0, sizeof(data));

    if (ret == FR_OK) {
        UINT readed = 0;
        // leave one byte for terminating 0
        ret = f_read(fd, (void*)data, sizeof(data) - 1, &readed);

        if (ret != FR_OK) {
            printFatFsError("log index file read", ret);
            logFileIndex = MIN_FILE_INDEX;
        } else {
            efiPrintf("Got content [%s] size %d", data, readed);
            logFileIndex = maxI(MIN_FILE_INDEX, atoi(data));
            if (absI(logFileIndex) == ATOI_ERROR_CODE) {
                logFileIndex = MIN_FILE_INDEX;
            } else {
                // next file would use next file name
                logFileIndex++;
            }
        }
        f_close(fd);
    } else if (ret == FR_NO_FILE) {
        // no index file - this is not an error, just an empty SD
        logFileIndex = MIN_FILE_INDEX;
    } else {
        printFatFsError("log index file open", ret);
        efiPrintf("%s: not found or error: %d", LOG_INDEX_FILENAME, ret);
        logFileIndex = MIN_FILE_INDEX;
    }

    // truncate or create new
    ret = f_open(fd, LOG_INDEX_FILENAME, FA_CREATE_ALWAYS | FA_WRITE);
    if (ret == FR_OK) {
        UINT writen = 0;
        size_t len = itoa10(data, logFileIndex) - data;
        ret = f_write(fd, (void*)data, len, &writen);
        if ((ret != FR_OK) || (len != writen)) {
            printFatFsError("log index write", ret);
        }
        f_close(fd);
    } else {
        printFatFsError("log index file write", ret);
    }

    efiPrintf("New log file index %d", logFileIndex);
}

Referenced by sdLogger().

Here is the call graph for this function:

Here is the caller graph for this function:

printFatFsError()

void printFatFsError	(	const char *	str,
		FRESULT	f_error
	)

Definition at line 273 of file mmc_card.cpp.

                                                       {
    static int fatFsErrors = 0;

    if (fatFsErrors++ > 16) {
        // no reason to spam the console
        return;
    }

    efiPrintf("%s FATfs Error %d %s", str, f_error, f_error <= FR_INVALID_PARAMETER ? fatErrors[f_error] : "unknown");
}

Referenced by incLogFileName(), sdFormat(), sdLoggerCreateFile(), and unmountMmc().

Here is the caller graph for this function:

writeErrorReportFile()

void writeErrorReportFile

(

)

Go to the source code of this file.
