Flash memory descriptor. More...
#include <fsl_ftfx_controller.h>
Data Fields | ||
| uint8_t | type | |
| uint8_t | index | |
| uint8_t | reserved [2] | |
| struct { | ||
| uint32_t isIndBlock:1 | ||
| uint32_t hasIndPfsizeReg:1 | ||
| uint32_t hasProtControl:1 | ||
| uint32_t hasIndProtReg:1 | ||
| uint32_t hasXaccControl:1 | ||
| uint32_t hasIndXaccReg:1 | ||
| uint32_t :18 | ||
| uint32_t ProtRegBits:8 | ||
| } | feature | |
| uint32_t | blockBase | |
| uint32_t | totalSize | |
| uint32_t | sectorSize | |
| uint32_t | blockCount | |
| ftfx_spec_mem_t | accessSegmentMem | |
| ftfx_spec_mem_t | protectRegionMem | |
Detailed Description
Flash memory descriptor.
Definition at line 249 of file fsl_ftfx_controller.h.
Field Documentation
◆ __pad0__
| uint32_t _ftfx_mem_descriptor::__pad0__ |
Definition at line 261 of file fsl_ftfx_controller.h.
◆ accessSegmentMem
| ftfx_spec_mem_t _ftfx_mem_descriptor::accessSegmentMem |
Definition at line 268 of file fsl_ftfx_controller.h.
◆ blockBase
| uint32_t _ftfx_mem_descriptor::blockBase |
A base address of the flash block
Definition at line 264 of file fsl_ftfx_controller.h.
◆ blockCount
| uint32_t _ftfx_mem_descriptor::blockCount |
A number of flash blocks.
Definition at line 267 of file fsl_ftfx_controller.h.
◆ [struct]
| struct { ... } _ftfx_mem_descriptor::feature |
◆ hasIndPfsizeReg
| uint32_t _ftfx_mem_descriptor::hasIndPfsizeReg |
Definition at line 256 of file fsl_ftfx_controller.h.
◆ hasIndProtReg
| uint32_t _ftfx_mem_descriptor::hasIndProtReg |
Definition at line 258 of file fsl_ftfx_controller.h.
◆ hasIndXaccReg
| uint32_t _ftfx_mem_descriptor::hasIndXaccReg |
Definition at line 260 of file fsl_ftfx_controller.h.
◆ hasProtControl
| uint32_t _ftfx_mem_descriptor::hasProtControl |
Definition at line 257 of file fsl_ftfx_controller.h.
◆ hasXaccControl
| uint32_t _ftfx_mem_descriptor::hasXaccControl |
Definition at line 259 of file fsl_ftfx_controller.h.
◆ index
| uint8_t _ftfx_mem_descriptor::index |
Index of flash block.
Definition at line 252 of file fsl_ftfx_controller.h.
◆ isIndBlock
| uint32_t _ftfx_mem_descriptor::isIndBlock |
Definition at line 255 of file fsl_ftfx_controller.h.
◆ protectRegionMem
| ftfx_spec_mem_t _ftfx_mem_descriptor::protectRegionMem |
Definition at line 269 of file fsl_ftfx_controller.h.
◆ ProtRegBits
| uint32_t _ftfx_mem_descriptor::ProtRegBits |
Definition at line 262 of file fsl_ftfx_controller.h.
◆ reserved
| uint8_t _ftfx_mem_descriptor::reserved[2] |
Definition at line 253 of file fsl_ftfx_controller.h.
◆ sectorSize
| uint32_t _ftfx_mem_descriptor::sectorSize |
The size in bytes of a sector of flash.
Definition at line 266 of file fsl_ftfx_controller.h.
◆ totalSize
| uint32_t _ftfx_mem_descriptor::totalSize |
The size of the flash block.
Definition at line 265 of file fsl_ftfx_controller.h.
◆ type
| uint8_t _ftfx_mem_descriptor::type |
Type of flash block.
Definition at line 251 of file fsl_ftfx_controller.h.
The documentation for this struct was generated from the following file:
- config/boards/kinetis/OS/os/hal/ports/KINETIS/KE1xF/fsl/fsl_ftfx_controller.h
