LPSPI slave configuration structure. More...
#include <fsl_lpspi.h>
Detailed Description
LPSPI slave configuration structure.
Definition at line 282 of file fsl_lpspi.h.
Field Documentation
◆ bitsPerFrame
| uint32_t _lpspi_slave_config::bitsPerFrame |
Bits per frame, minimum 8, maximum 4096.
Definition at line 284 of file fsl_lpspi.h.
Referenced by LPSPI_SlaveGetDefaultConfig(), and LPSPI_SlaveInit().
◆ cpha
| lpspi_clock_phase_t _lpspi_slave_config::cpha |
Clock phase.
Definition at line 286 of file fsl_lpspi.h.
Referenced by LPSPI_SlaveGetDefaultConfig(), and LPSPI_SlaveInit().
◆ cpol
| lpspi_clock_polarity_t _lpspi_slave_config::cpol |
Clock polarity.
Definition at line 285 of file fsl_lpspi.h.
Referenced by LPSPI_SlaveGetDefaultConfig(), and LPSPI_SlaveInit().
◆ dataOutConfig
| lpspi_data_out_config_t _lpspi_slave_config::dataOutConfig |
Configures if the output data is tristated between accesses (LPSPI_PCS is negated).
Definition at line 295 of file fsl_lpspi.h.
Referenced by LPSPI_SlaveGetDefaultConfig(), and LPSPI_SlaveInit().
◆ direction
| lpspi_shift_direction_t _lpspi_slave_config::direction |
MSB or LSB data shift direction.
Definition at line 287 of file fsl_lpspi.h.
Referenced by LPSPI_SlaveGetDefaultConfig(), and LPSPI_SlaveInit().
◆ pcsActiveHighOrLow
| lpspi_pcs_polarity_config_t _lpspi_slave_config::pcsActiveHighOrLow |
Desired PCS active high or low
Definition at line 290 of file fsl_lpspi.h.
Referenced by LPSPI_SlaveGetDefaultConfig(), and LPSPI_SlaveInit().
◆ pinCfg
| lpspi_pin_config_t _lpspi_slave_config::pinCfg |
Configures which pins are used for input and output data during single bit transfers.
Definition at line 292 of file fsl_lpspi.h.
Referenced by LPSPI_SlaveGetDefaultConfig(), and LPSPI_SlaveInit().
◆ whichPcs
| lpspi_which_pcs_t _lpspi_slave_config::whichPcs |
Desired Peripheral Chip Select (pcs)
Definition at line 289 of file fsl_lpspi.h.
Referenced by LPSPI_SlaveGetDefaultConfig(), and LPSPI_SlaveInit().
The documentation for this struct was generated from the following file:
- config/boards/kinetis/OS/os/hal/ports/KINETIS/KE1xF/fsl/fsl_lpspi.h
