#include <scheduler.h>

Inheritance diagram for Scheduler:

Public Member Functions
virtual void	schedule (const char msg, scheduling_s scheduling, efitick_t targetTime, action_s const &action)=0
	Schedule an action to be executed in the future.

virtual void	cancel (scheduling_s *scheduling)=0
	Cancel the specified scheduling_s so that, if currently scheduled, it does not execute.

Detailed Description

Definition at line 305 of file scheduler.h.

Member Function Documentation

virtual void Scheduler::cancel ( scheduling_s * scheduling )

pure virtual

Cancel the specified scheduling_s so that, if currently scheduled, it does not execute.

Parameters

scheduling The scheduling_s to cancel.

virtual void Scheduler::schedule	(	const char *	msg,
		scheduling_s *	scheduling,
		efitick_t	targetTime,
		action_s const &	action
	)

pure virtual

Schedule an action to be executed in the future.

scheduleByAngle is useful if you want to schedule something in terms of crank angle instead of time.

Parameters

msg	Name of this event to use for logging in case of an error.
scheduling	Storage to use for the scheduled event. If null, one will be used from the pool.
targetTime	When to execute the specified action. If this time is in the past or very near future, it may execute immediately.
action	An action to execute at the specified time.

Here is the caller graph for this function:

The documentation for this struct was generated from the following file:
