#include <fuel_computer_generated.h>
Data Fields | |
| float | postCrankingFuelCorrection = (float)0 |
| float | intakeTemperatureCoefficient = (float)0 |
| float | coolantTemperatureCoefficient = (float)0 |
| float | timeSinceCrankingInSecs = (float)0 |
| scaled_channel< uint16_t, 100, 1 > | baseFuel = (uint16_t)0 |
| scaled_channel< uint16_t, 100, 1 > | fuel = (uint16_t)0 |
Detailed Description
Definition at line 7 of file fuel_computer_generated.h.
Field Documentation
◆ baseFuel
| scaled_channel<uint16_t, 100, 1> running_fuel_s::baseFuel = (uint16_t)0 |
@GAUGE_NAME_FUEL_BASE@ This is the raw value we take from the fuel map or base fuel algorithm, before the corrections units: mg offset 16
Definition at line 34 of file fuel_computer_generated.h.
Referenced by getOutputValueByName(), and getRunningFuel().
◆ coolantTemperatureCoefficient
| float running_fuel_s::coolantTemperatureCoefficient = (float)0 |
@GAUGE_NAME_FUEL_CLT_CORR@ offset 8
Definition at line 22 of file fuel_computer_generated.h.
Referenced by getOutputValueByName(), getRunningFuel(), and EngineState::periodicFastCallback().
◆ fuel
| scaled_channel<uint16_t, 100, 1> running_fuel_s::fuel = (uint16_t)0 |
@GAUGE_NAME_FUEL_RUNNING@ Total fuel with CLT IAT and TPS acceleration without injector lag corrections per cycle, as pulse per cycle units: mg offset 18
Definition at line 41 of file fuel_computer_generated.h.
Referenced by getOutputValueByName(), and getRunningFuel().
◆ intakeTemperatureCoefficient
| float running_fuel_s::intakeTemperatureCoefficient = (float)0 |
@GAUGE_NAME_FUEL_IAT_CORR@ offset 4
Definition at line 17 of file fuel_computer_generated.h.
Referenced by getOutputValueByName(), getRunningFuel(), and EngineState::periodicFastCallback().
◆ postCrankingFuelCorrection
| float running_fuel_s::postCrankingFuelCorrection = (float)0 |
Fuel: Post cranking mult offset 0
Definition at line 12 of file fuel_computer_generated.h.
Referenced by getOutputValueByName(), getRunningFuel(), and EngineState::periodicFastCallback().
◆ timeSinceCrankingInSecs
| float running_fuel_s::timeSinceCrankingInSecs = (float)0 |
units: secs offset 12
Definition at line 27 of file fuel_computer_generated.h.
Referenced by IdleController::determinePhase(), IdleController::getIdleTimingAdjustment(), getOutputValueByName(), EngineState::periodicFastCallback(), and shouldCorrect().
The documentation for this struct was generated from the following file:
- controllers/algo/fuel/fuel_computer_generated.h
