Detailed Description

Date: Feb 26, 2021

Author: Matthew Kennedy, (c) 2021

Definition in file mpu_util.cpp.

Functions
bool	mcuCanFlashWhileRunning ()

size_t	flashSectorSize (flashsector_t)
	Get the size of `sector`.

uintptr_t	getFlashAddrFirstCopy ()

uintptr_t	getFlashAddrSecondCopy ()

Function Documentation

◆ flashSectorSize()

size_t flashSectorSize ( flashsector_t sector )

Get the size of sector.

Returns: sector size in bytes.

Definition at line 20 of file mpu_util.cpp.

                                        {
    // All sectors on H7 are 128k
    return 128 * 1024;
}

Referenced by intFlashSectorBegin(), and intFlashSectorErase().

Here is the caller graph for this function:

◆ getFlashAddrFirstCopy()

uintptr_t getFlashAddrFirstCopy ( void )

Flex Non Volatile Memory is faster than flash It also has smaller pages so it takes less time to erase

There is no remote access to FlexNVM meaning that we cannot erase settings externally

Definition at line 27 of file mpu_util.cpp.

                                  {
#ifdef STM32H723xx
    return 0x080E0000;
#else
    return 0x08100000;
#endif
}

◆ getFlashAddrSecondCopy()

uintptr_t getFlashAddrSecondCopy ( void )

Definition at line 35 of file mpu_util.cpp.

                                   {
#ifdef STM32H723xx
    return 0;
#else
    // Second copy is one sector past the first
    return getFlashAddrFirstCopy() + 128 * 1024;
#endif
}

Here is the call graph for this function:

◆ mcuCanFlashWhileRunning()

bool mcuCanFlashWhileRunning ( )

Definition at line 12 of file mpu_util.cpp.

                               {
#ifdef STM32H723xx
    return false;
#else
    return true;
#endif
}
