tle8888.h File Reference

Data Structures
struct	tle8888_config

Functions
int	tle8888_add (brain_pin_e base, unsigned int index, const struct tle8888_config *cfg)
void	tle8888_req_init ()
void	tle8888_dump_regs ()
void	tle8888PostState ()

Function Documentation

tle8888_add()

int tle8888_add	(	brain_pin_e	base,
		unsigned int	index,
		const struct tle8888_config *	cfg
	)

Returns

return gpio chip base

tle8888_dump_regs()

void tle8888_dump_regs

(

)

Definition at line 1279 of file tle8888.cpp.

                         {
    auto& chip = chips[0];

    // since responses are always in the NEXT transmission we will have this one first
    chip.read_reg(0, NULL);

    efiPrintf("register: data");
    for (int request = 0; request <= 0x7e + 1; request++) {
        uint16_t tmp;
        chip.read_reg(request < (0x7e + 1) ? request : 0x7e, &tmp);
        uint8_t reg = getRegisterFromResponse(tmp);
        uint8_t data = getDataFromResponse(tmp);

        efiPrintf("%02x: %02x", reg, data);
    }
}

Referenced by initPinRepository().

Here is the caller graph for this function:

tle8888_req_init()

void tle8888_req_init

(

)

Definition at line 1272 of file tle8888.cpp.

                        {
    auto& tle = chips[0];

    tle.need_init = true;
    tle.init_req_cnt++;
}

Referenced by handleCommandX14(), initPinRepository(), and tle8888startup().

Here is the caller graph for this function:

tle8888PostState()

void tle8888PostState

(

)

Definition at line 279 of file tle8888.cpp.

                        {
    Tle8888 *chip = &chips[0];

    engine->outputChannels.debugIntField1 = chip->wwd_err_cnt;
    engine->outputChannels.debugIntField2 = chip->fwd_err_cnt;
    engine->outputChannels.debugIntField3 = chip->tot_err_cnt;
    //engine->outputChannels.debugIntField1 = chip->spi_cnt;
    //engine->outputChannels.debugIntField2 = chip->tx;
    //engine->outputChannels.debugIntField3 = chip->rx;
    engine->outputChannels.debugIntField5 = chip->init_cnt;

    engine->outputChannels.debugFloatField3 = chip->OpStat[1];
    engine->outputChannels.debugFloatField4 = chip->por_cnt * 1000000 + chip->init_req_cnt * 10000;
    engine->outputChannels.debugFloatField5 = 0;
    engine->outputChannels.debugFloatField6 = 0;
}

Go to the source code of this file.
